Required Tools
Diagnostic Tools
- Eaton Breakout Box with 74-Way Eaton Diagnostic Adapter - RR1029TR
- 3-Way Eaton Diagnostic Adapter - RR1060TR
- Rail B Synchronizer Engagement Tool - RR1088TR
- MTM Alignment Tool - RR1086TR-1
- 0-200 psi (0-1379 kPa) air pressure gauge
Available at www.klineind.com or contact K-Line at 1-800-824-5546
Volt/Ohm Meter
- Digital Volt/Ohm Meter (DVOM)
PC-Based Service Tool
- ServiceRanger
- Approved Communication Adapter
- 9-Pin Deutsch Diagnostic Adapter
Service Publications
Publication | Title |
---|
TRSM0950 | Endurant HD Automated Transmission Service Manual |
TRDR0950 | Endurant HD Automated Transmission Driver Instructions |
TCMT0072 | ServiceRanger™ User’s Guide |
TCMT0073 | ServiceRanger™ Quick Start Guide |
TCMT0020 | Eaton Approved Lubricant Suppliers |
TCMT0021 | Roadranger Lubricant Products Manual |
TRIG0950 | Installation Guide |
TRIG2610 | PTO Installation Guide |
TCWY0900 | Eaton Warranty Guide |
For additional information, go to www.EatonCummins.com.
- Contact Eaton Cummins Automated Transmission Technologies for further diagnostic instructions.
- Refer to WYIB-0002 Roadranger Call Center Pre-Call Checklist and collect all the required information prior to contacting Eaton Cummins.
- For Help Line phone numbers, see Contact Information.
Contact Information
- U.S. and Canada Help Line: +1-800-826-4357
- Mexico Help Line: +52-800-800-6801
![_Graphics/Raster/ContactQR.png _Graphics/Raster/ContactQR.png](/book-translation/593/asset/_Graphics/Raster/ContactQR.png)
