Endurant HD
TRTS0950 EN-US
|
April 2025 - A

Manually Vent Linear Clutch Actuator (LCA) Procedure

Component Identification

_Graphics/LineArt/TRTS0950_LCA_Venting_ComponentID.png

1. Linear Clutch Actuator (LCA)

Procedure - Manually Vent LCA

  • Set vehicle parking brake and chock wheels.
  • Loosen (do not remove) the 4 LCA cap screws 1-2 turns with a T45 Torx.

    Note: Residual air pressure in the LCA cylinder exhausts between the LCA and MTM housings when the cap screws are loosened.

    _Graphics/LineArt/TRTS0950_LCA_Venting_LoosenBolts.png
  • Torque the 4 LCA cap screws to 23-27 Nm.
